From Silicon To Self-Reliance: India Breaks Ground On First 3D Semiconductor Packaging Unit

On April 19, 2026, Odisha hosted the groundbreaking ceremony for India’s first advanced 3D chip packaging unit. The event was led by Chief Minister Mohan Charan Majhi and Union Electronics & IT Minister Ashwini Vaishnaw, alongside senior officials, investors, and academic representatives.

Project Details

The facility, titled Heterogeneous Integration Packaging Solutions (3D Glass Solutions), introduces glass substrate-based advanced semiconductor packaging technology. Located at Info Valley, Bhubaneswar, the plant positions Odisha as a future-ready hub for semiconductor innovation.

Strategic Importance

This project is a cornerstone of India’s Atmanirbhar Bharat vision, aiming to reduce dependence on imported chips and strengthen domestic manufacturing. The advanced packaging technology will enable higher performance, energy efficiency, and miniaturization critical for next-generation electronics.

Applications And Impact

The unit is expected to boost India’s capabilities in AI, 5G, defence, and consumer electronics, while also creating new opportunities for research and skill development. By attracting global partnerships, Odisha is set to emerge as a key player in the semiconductor value chain.

Key Highlights

•⁠  ⁠Groundbreaking held on April 19, 2026, in Bhubaneswar, Odisha

•⁠  ⁠India’s first advanced 3D semiconductor packaging unit launched

•⁠  ⁠Project titled Heterogeneous Integration Packaging Solutions (3D Glass Solutions)

•⁠  ⁠Backed by global industry leaders and investors

•⁠  ⁠Boosts India’s semiconductor ecosystem, AI, 5G, and defence tech

•⁠  ⁠Supports Atmanirbhar Bharat vision for self-reliance in electronics manufacturing

Sources: Indiablooms, Pragativadi, Odisha Bytes, The News Insight, India News Diary
